Allen-Bradley 505-EOD Size 4 Reversing Contactor 100HP-MAKE OFFER!
For sale is an Allen-Bradley 505-EOD Size 4 Contactor 600V 135A 100HP 575V.
This contactor came from a 40-year-old 400-ton press but is a recent
replacement. The former owner of the press told me it was
installed 5-8 years ago. It clearly is far cleaner and less grimy
than the rest of the electrical equipment in the press cabinet.
I opened it up to look at contacts.
The large silver contacts are in very good condition, I
would say around 90%.
Allen-Bradley industrial contactor/starter assembly mounted on a steel
base. Visible nameplate on one contactor: Cat. 505-EOD, Size 4, 135A
max continuous, 600V AC max. HP ratings on label: 40 HP at 200V, 50 HP
at 230V, 100 HP at 460?575V. Terminals labeled L1/L2/L3 and T1/T2/T3.
Two large contactor blocks are linked with red control wiring; an
overload/terminal block is present on the load side.
Condition: used. Scuffs, dust, oxidation on terminals, cut leads, and
electrical tape on some conductors. No enclosure. Exactly what?s shown
is included.
Assumption: a small tag shows 115?120V on one component, but coil
voltage for the main contactors is not verified.
Typical use: industrial motor control, panel builds, replacement or
parts.
Nameplate Data (please verify independently):
CAT. 505-E0D
H.P. MAX. 200V 230V
3˜ 3-5 P
40 H.P. 50 H.P. 100 H.P.
135 A. MAX. CONT. 600V ~ MAX.
CAMBRIDGE
ALLEN-BRADLEY
ONT. CANADA
