Allen-Bradley PowerFlex 4M 22F-D2P5N103 VFD 1HP 480V 3PH

Allen-Bradley PowerFlex 4M 22F-D2P5N103 VFD 1HP 480V 3PH

For sale is a Allen-Bradley PowerFlex 4M 22F-D2P5N103 VFD 1HP 480V 3PH.
Allen-Bradley PowerFlex 4M variable frequency drive (VFD). Cat No.
22F-D2P5N103, Series A, FW 2.02. IP20 open type. Date code 2023-04-26.

Ratings (from label): Motor 0.75 kW / 1 HP. Input: 3-phase 380?480 VAC,
48?63 Hz, 3.5 A (voltage range 342?528). Output: 3-phase 0?460 VAC,
0?400 Hz, 2.5 A continuous, 3.75 A for 60 s. SCCR 100 kA.

Features: Built-in keypad/display with pot and start/stop buttons.
Screw terminal connections.

Condition: Used. Visible dust, scuffs, and marks from prior
installation. Some short wire stubs remain on terminals. Labels intact.
No cracks seen on housing.

Included: Drive only as shown. No manuals, cables, or additional
accessories.

Use cases: Speed control of 3-phase induction motors for conveyors,
pumps, fans, and general automation.

Testing: Functionality not tested; sold as untested.


Price: $99
